Professional High-quality OEM EV Insulated Busbar Bending Machine Custom Nantes Factory-Fengxie

1.Specially designed for insulated busbars: structure and tooling are optimized for plastic-coated copper/aluminum busbars to prevent insulation damage and rebound.
2.Multi-angle bending capability: supports U-shape, Z-shape, L-shape and other complex bends to meet diverse wiring layouts.
3.High level of automation: full-servo drive system ensures stable operation and precise angle control.
4.Supports 3D drawing import: auto-generates bending programs and simulates bending paths to reduce setup time and material cost.
5.Customizable tooling: bending radius and structure can be tailored based on insulation thickness and material hardness.
6.High-efficiency production: easy to operate with fast tool change, suitable for flexible and multi-variety manufacturing.

Model	FX-45E-10
Processing Capacity	Thickness : 2.0mm ~ 10.0mm Width : 13.0mm ~ 45.0mm
Axis	13-16
Wire Feed Wheel Sets	4Sets
Wire Feeding Motor Power	7.5KW
Wire Rotation Motor Power	4.5KW
Mandrel Rotation Motor Power	2.0KW
Slide Motor Power	4.5KW×8
Spinner Motor Power	2.0KW
Cutter Motor Power	1.5KW
Dimension (LxWxH)	3650X2500X2450（mm3）
Weight	7500kg
