Professional High-end OEM/ODM Toulouse Automatic Busbar Bending, Punching and Cutting Machine Custom Processing Maker-Fengxie

1.Integrated design: combines bending, punching, and cutting in one machine, significantly improving productivity while saving labor and space.
2.Supports flat and vertical bending: adaptable to different busbar structures and complex processing requirements.
3.High processing accuracy: equipped with high-performance servo systems and CNC control to ensure dimensional consistency and stability.
4.Smart control system: equipped with industrial controller, supports 3D drawing import and auto-programming with visual path simulation, easy operation and short setup time.
5.Compatible with various coil materials: processes copper, aluminum, and other busbar types in different sizes.
6.Customizable solutions: optional features like automatic loading/unloading and laser marking are available to meet specific process requirements.

Model	FX-35TP-5
Processing Capacity	Thickness : 2.0mm ≤ T ≤ 5.0mm Width : 10.0mm ≤ W ≤ 35.0mm
Axis	10
Wire Feed Wheel Sets	4
Wire Feeding Motor Power	2.7kw
Slide Motor Power	2.0KWx3
Spinner Motor Power	2.0KWx2
Punching Motor Power	7.5KW
Cutter Moving Motor Power	0.75KW
Punch Head Moving Motor Power	0.75KW
Mold Moving Motor Power	1.2KW
Cutter Motor Power	1.5KW
Punching Force	19T
Dimension(LxWxH)	2600X2300X2500(mm3)
Weight	2500kg
